Display assembly
Description Spare part number
Display assemblies for use with computer models equipped with WLAN and WWAN capability (includes 3 WLAN antenna
transceivers and cables and 2 WWAN antenna transceivers and cables)
15.4-inch, WXGA
495043-001
15.4-inch, WSXGA+ 495044-001
15.4-inch, WUXGA 495045-001
Display assemblies for use with HP EliteBook 8530w computer models equipped with WLAN and WWAN capability (includes
3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
15.4-inch, WXGA
495046-001
15.4-inch, WSXGA+ 495047-001
15.4-inch, WUXGA 495048-001
Display assemblies for use with computer models equipped WLAN and WWAN capability and integrated webcam (includes 3
WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
15.4-inch, WXGA
495049-001
15.4-inch, WSXGA+ 495050-001
15.4-inch, WUXGA 495051-001
Display assemblies for use with HP EliteBook 8530w computer models equipped with WLAN and WWAN capability and
integrated webcam (includes 3 WLAN antenna transceivers and cables and 2 WWAN antenna transceivers and cables)
15.4-inch, WXGA
506809-001
15.4-inch, WSXGA+ 506810-001
15.4-inch, WUXGA 506811-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 45).
5. Disconnect the wireless antenna cables from the WLAN module (see
WLAN module on page 68)
and the WWAN module (see
WWAN module on page 58).
6. Remove the following components:
a. Keyboard (see
Keyboard on page 56)
b. Switch cover (see
Switch cover on page 69)
Component replacement procedures 73
