HP EliteBook 8530p User Manual

WLAN module
CAUTION: The WLAN module and the WWAN module are not interchangeable.
Description Spare part number
Intel Wi-Fi Link 5100 802.11a/b/g/n 1x2 WLAN module with iAMT 4.0 support:
●
For use in Antigua and Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, Brunei,
Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador,
El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia,
Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, Uruguay, the United States,
Venezuela, and Vietnam
480985-001 or
506678-001
Intel Wi-Fi Link 5300 802.11a/b/g/n 3x3 WLAN module with iAMT 4.0 support:
●
For use in Antigua and Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, Brunei,
Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador,
El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia,
Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, Uruguay, the United States,
Venezuela, and Vietnam
480986-001 or
506679-001
Intel Wi-Fi Link 5100 802.11 a/b/g 1x2 WLAN Module with iAMT 4.0 support:
●
For use in Russia, Ukraine, and Pakistan 482957-001 or
506808-001
Before removing the WLAN module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 45).
5. Remove the keyboard (see
Keyboard on page 56).
6. Remove the TouchPad (see
TouchPad on page 66).
Remove the WLAN module:
1. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.
NOTE: The black WLAN antenna cable is connected to the WLAN module “Main” terminal. The
white WLAN antenna cable is connected to the WLAN module “Aux” terminal. If the computer is
equipped with an 802.11a/b/g/n WLAN module, the yellow WLAN antenna cable (2) is connected
to the middle terminal on the WLAN module.
2. Remove the two Phillips PM2.0×4.0 barrel screws(3) that secure the WLAN module to the
computer. (The edge of the module opposite the slot rises away from the computer.)
68 Chapter 4 Removal and replacement procedures

HP EliteBook 8530p Specifications

General

Bus type	FSB
Stepping	E0
Tjunction	105 °C
Processor cache	6 MB
Processor cores	2
Processor model	T9400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T9000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.53 GHz
Processor cache type	L2
Processor technology	Intel Centrino 2 w/ vPro
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® PM45 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Display surface	Matt
Display diagonal	15.4 \
Display resolution	1680 x 1050 pixels
Native aspect ratio	16:10
Type	PC
Minimum RAM	1000 MB
Modem speed	56 Kbit/s
Battery type	8-cell (73 WHr) Lithium-Ion
Expansion slots	1 Express Card/54; 1 media card reader
Rear ports note	1 external VGA monitor; 1 AC power
Size (imperial)	14 \
Power management	8-cell (73 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery, optional HP (95 WHr) Ultra-Capacity Battery
Power supply type	External 120-watt Smart AC adapter; HP Fast Charge
Weight (imperial)	Weight varies by configuration and component. Starting at 6.3 lb lbs
Dimensions (WxDxH)	355 x 263.5 x 28.2 mm
Wireless technology	802.11a/b/g/n
Manageability features	HP 3D DriveGuard
Compatible operating systems	Genuine Windows Vista Business 64; Genuine Windows Vista Enterprise
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Discrete graphics card model	AMD Mobility Radeon HD 3650
Maximum graphics card memory	0.256 GB
Discrete graphics card memory	0.25 GB
Audio system	HD Audio
Audio included	High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated dual-microphone array
Bluetooth version	2.0+EDR
Networking features	Gigabit Ethernet, WLAN
Bundled software	HP Recovery Manager, HP Client Manager Software, HP Client Configuration Management Agent, HP OpenView PC Configuration Management Solutions
Operating system installed	Windows Vista Business
Optional operating system supplied	Windows XP Professional
Number of battery cells	8
I/O ports	4 USB 2.0; 1 1394a; 1 RJ-11; 1 RJ-45; 1 microphone in; 1 headphone/line-out; 1 docking connector; 1 HDMI; 1 battery connector; 1 eSATA
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	4
AC adapter power	120 W
Keyboard type	101/102-key compatible keyboard with HP DuraKeys
Pointing device	Touchpad + Scroll zone
Certification	ENERGY STAR qualified
Storage drive type	250 GB 7200 rpm SATA II
Video card features	ATI Mobility RadeonTM HD 3650
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Non-operating relative humidity (non-condensing)	5 - 90 %
Processor code	SLGEK
Processor ARK ID	35562
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	263.5 mm
Width	355 mm
Weight	2860 g
Height (front)	28.2 mm
