Item Description Spare part number
With 3 TouchPad buttons and 3 pointing stick buttons for use with keyboards with pointing
stick (includes TouchPad cable)
(6) WWAN module
HP un2400 Mobile Broadband Module 483337-001
(7) Fan
For use with the HP EliteBook 8530p computer models or the HP EliteBook 8530w computer
models
495079-001
For use with the Quad Core processor 495080-001
Heat sink (includes a heat sink clip and replacement thermal material)
Thermal Material Kits (not illustrated)
For use with the Quad Core processor and nVidia graphics card 501116-001
For use with the Quad Core processor and ATI graphics card 495074-001
For use with the Dual Core processor and nVidia graphics card 495075-001
For use with the Dual Core processor and ATI graphics card 501117-001
(8) Graphics cards (include replacement thermal material)
ATI M86M ATI Mobility Radeon HD 3650 graphics card with 256 MB of graphics subsystem
memory (supports Hypermemory)
495081-001
ATI M86M ATI Mobility FireGL V700 graphics card with 256 MB of graphics subsystem
memory (supports Hypermemory)
502337-001
nVidia NB9P-GLM2 graphics card with 512 MB of graphics subsystem memory (supports
Quadro FX 770M)
502338-001
Plastics Kit (see Plastics Kit on page 27 for more Plastics Kit spare part information): 495076-001
(9a) ExpressCard slot protective insert
(9b) Memory module compartment cover
(9c)
Bluetooth module cover
(9d) Hard drive cover
Base enclosure rubber screw covers (2, not illustrated)
Computer feet (4, not illustrated)
(10)
Processors
Intel Core2 Extreme processors
QX9300 2.53-GHz Quad Core processor (12-MB L2 cache, 1066-MHz FSB) 501107-001
X9100 Dual Core, 3.06-GHz processor (6-MB L2 cache, 1066-MHz FSB) 501106-001
Intel Core2 Duo processors
T9600 2.8-GHz processor (6-MB L2 cache, 1066-MHz FSB) 495041-001
T9400 2.53-GHz processor (6-MB L2 cache, 1066-MHz FSB) 495040-001
P8600 2.4-GHz processor (3-MB L2 cache, 1066-MHz FSB) 495039-001
24 Chapter 3 Illustrated parts catalog
