NOTE: Be sure to support the display when removing the screws.
4. Remove the four Phillips PM2.5×4.0 screws (1) that secure the display assembly to the computer.
5. Remove the display assembly from the top cover (2).
6. To remove the display bezel:
a. Flex the inside edges of the bottom edge (1), the left and right sides (2), and the top edge (3) of
the display bezel until the bezel disengages from the display enclosure.
b. Remove the display bezel (4). The display bezel is available using spare part number 769705-001
on models with a webcam and 769706-001 on models without a webcam.
NOTE: For this procedure the display will not be connected to the computer as shown in the
following image.
68 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
