2. Remove the Phillips PM2.0 × 3.0 screw (1) that secures the solid-state drive to the system board.
3. Pull the drive (2) away from the socket to remove it.
To install the solid-state drive, reverse the removal procedures.
NOTE: Solid-state drives are designed with a notch to prevent incorrect insertion.
WWAN module
To remove the WWAN module, use this procedure and illustration.
46 Chapter 5 Removal and replacement procedures for authorized service provider parts ENWW
