Bottom cover
NOTE: The bottom cover spare part kit includes magnets and front and rear rubber foot strips.
Description Spare part number
For use only on computer models equipped with WLAN capability L41026-001
For use only on computer models equipped with WWAN capability L41025-001
Before disassembling the computer, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
Remove the bottom cover:
1. Turn the computer upside down with the front toward you.
2. Remove the six Torx5 M2.0×5.0 screws that secure the bottom cover to the computer.
3. Use a case utility tool (1) or similar thin plastic tool to separate the front edge of the bottom cover from
the keyboard/top cover.
Component replacement procedures 27
