Display assembly
Description Spare part number
14.0-inch, UHD (3840×2160), BrightView, WLED, UWVA, 72, 500 nits, eDP+PSR, ultraslim TouchScreen
display assembly for use with computer models equipped with WWAN capability (includes left and right
WWAN antenna cables and transceivers)
L42962-001
14.0-inch, FHD (1920×1080), AntiGlare, WLED, UWVA, 72, 700 nits, eDP+PSR, ultraslim TouchScreen
display assembly with privacy lter for use with computer models equipped with WLAN capability (includes
left and right WLAN antenna cables and transceivers)
L42311-001
14.0-inch, FHD (1920×1080), AntiGlare, WLED, UWVA, 72, 700 nits, eDP+PSR, ultraslim TouchScreen
display assembly with privacy lter for use with computer models equipped with WLAN capability (includes
left and right WLAN antenna cables and transceivers)
L41028-001
14.0-inch, FHD (1920×1080), AntiGlare, WLED, UWVA, 72, 700 nits, eDP+PSR, ultraslim TouchScreen
display assembly with privacy lter for use with computer models equipped with WWAN capability (includes
left and right WWAN antenna cables and transceivers)
L42310-001
14.0-inch, FHD (1920×1080), AntiGlare, WLED, UWVA, 72, 400 nits, eDP+PSR, ultraslim TouchScreen
display assembly for use with computer models equipped with WLAN capability (includes left and right
WLAN antenna cables and transceivers)
L42308-001
14.0-inch, FHD (1920×1080), AntiGlare, WLED, UWVA, 72, 400 nits, eDP+PSR, ultraslim TouchScreen
display assembly for use with computer models equipped with WLAN capability (includes left and right
WLAN antenna cables and transceivers)
L42309-001
14.0-inch, FHD (1920×1080), BrightView, WLED, UWVA, 72, 400 nits, eDP+PSR, ultraslim TouchScreen
display assembly for use with computer models equipped with WLAN capability (includes left and right
WLAN antenna cables and transceivers)
L41027-001
14.0-inch, FHD (1920×1080), BrightView, WLED, UWVA, 72, 400 nits, eDP+PSR, ultraslim TouchScreen
display assembly for use with computer models equipped with WWAN capability (includes left and right
WWAN antenna cables and transceivers)
L42307-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 27).
5. Remove the battery (see Battery on page 28).
6. Remove the system board (see System board on page 41).
Remove the display assembly:
1. Remove the six Phillips M2.5×5.7 screws that secure the display hinges to the keyboard/top cover.
48 Chapter 5 Removal and replacement procedures
