3. Push and hold the green tab (1) while pushing in the green latch (2) at the back of the optical disc drive
enclosure and slide the drive (3) out of the chassis.
4. Pull the green latch o the optical disc drive.
Keep this latch to install on the new optical disc drive.
5. Align the three pins on the latch with the holes in the new optical disc drive and press the latch rmly onto
the new drive.
NOTE: You must reuse the latch removed from the old optical disc drive.
Replacing drives 33
