HP EliteOne 800 Hardware Reference Guide

Replacing the battery
The battery is located on the system board on the lower right side of the fan. The battery that comes
with the computer provides power to the real-time clock. When replacing the battery, use a battery
equivalent to the battery originally installed in the computer. The computer comes with a 3-volt lithium
coin cell battery.
WARNING! The computer contains an internal lithium manganese dioxide battery. There is a risk of
fire and burns if the battery is not handled properly. To reduce the risk of personal injury:
Do not attempt to recharge the battery.
Do not expose to temperatures higher than 60 °C (140 ºF).
Do not disassemble, crush, puncture, short external contacts, or dispose of in fire or water.
Replace the battery only with the HP spare designated for this product.
CAUTION: Before replacing the battery, it is important to back up the computer CMOS settings.
When the battery is removed or replaced, the CMOS settings will be cleared.
Static electricity can damage the electronic components of the computer or optional equipment.
Before beginning these procedures, be sure that you are discharged of static electricity by briefly
touching a grounded metal object.
NOTE: The lifetime of the lithium battery can be extended by plugging the computer into a live AC
wall socket. The lithium battery is only used when the computer is NOT connected to AC power.
HP encourages customers to recycle used electronic hardware, HP original print cartridges, and
rechargeable batteries. For more information about recycling programs, go to
http://www.hp.com/
recycle.
1. Remove all removable media, such as compact discs or USB flash drives, from the computer.
2. Turn off the computer properly through the operating system, then turn off any external devices.
3. Disconnect the power cord from the power outlet and disconnect any external devices.
CAUTION: You must disconnect the power cord and wait approximately 30 seconds for the
power to drain before adding or removing memory modules. Regardless of the power-on state,
voltage is always supplied to the memory modules as long as the computer is plugged into an
active AC outlet. Adding or removing memory modules while voltage is present may cause
irreparable damage to the memory modules or system board.
4. Remove/disengage any security devices that prohibit opening the computer.
5. Place the computer face down on a soft flat surface. HP recommends that you set down a
blanket, towel, or other soft cloth to protect the bezel and screen surface from scratches or other
damage.
Replacing the battery 33

HP EliteOne 800 Specifications

General

Full HD	Yes
Display diagonal	23 \
Touch technology	Multi-touch
Native aspect ratio	16:9
Tcase	71.35 °C
Bus type	QPI
Stepping	C0
Processor code	SR14J
Processor cache	6 MB
Processor cores	4
Processor model	i5-4570S
System bus rate	- GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4500 Desktop Series
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Number of QPI links	1
Processor frequency	2.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	65 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Product type	All-in-One PC
Motherboard chipset	Intel® Q87
Memory slots	2
Internal memory	8 GB
Memory slots type	SO-DIMM
Memory clock speed	1600 MHz
Maximum internal memory	- GB
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1000 GB
Compatible memory cards	SD
Intel segment tagging	Enterprise
Storage drive interface	Serial ATA
On-board graphics card ID	0x412
On-board graphics card model	Intel® HD Graphics 4600
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Audio system	DTS Studio Sound
Wi-Fi standards	Not supported
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Operating system installed	Windows 8 Pro
Scalability	1S
Processor ARK ID	75044
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013C
Intel Identity Protection Technology version	1.00
Product color	Black
Country of origin	China
Total megapixels	2 MP
AC adapter power	200 W
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth (with stand)	503 mm
Width (with stand)	560 mm
Height (with stand)	389 mm
Weight (with stand)	7890 g
