HP EliteOne 800

8. Pull the latch off the optical disc drive.
Figure 2-42 Removing the optical disc drive latch
9. Remove the cover from the adhesive strip on the new latch. Align the two pins on the latch with
the holes in the new optical disc drive and press the latch onto the drive firmly.
NOTE: You may reuse the latch removed from the old optical disc drive.
Figure 2-43 Attaching the optical disc drive latch
42 Chapter 2 Hardware repair and upgrade
