HP ENVY PRO User Manual

Audio board
The audio board is located near the bottom, left side of the computer.
To remove the audio board:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 17).
2. Remove the bezel (see Bezel on page 23).
3. Remove the display panel (see Display panel on page 26).
4. Disconnect the cable from the audio board (1).
5. Remove the two Phillips screws (2) that secure the trim to the computer.
6. Remove the audio board from the computer (3).
To install the audio board, reverse the removal procedures.
Audio board 33

HP ENVY PRO Specifications

General

Processor	Intel Core i5 or i7
Graphics	Intel UHD Graphics
Operating System	Windows 10 Home or Pro
Ports	HDMI, Ethernet
Wireless	Wi-Fi 6 (802.11ax), Bluetooth 5.0
