HP ENVY x2 User Manual

Using Windows Refresh for quick and easy recovery
When your computer is not working properly and you need to regain system stability, the Windows
Refresh option allows you to start fresh and keep what is important to you.
IMPORTANT: Refresh removes any traditional applications that were not originally installed on the
system at the factory.
NOTE: During Refresh, a list of removed traditional applications will be saved so that you have a
quick way to see what you might need to reinstall. See HP Support Assistant for instructions on
reinstalling traditional applications. To access HP Support Assistant, on the Start screen, select the
HP Support Assistant app.
NOTE: You may be prompted for your permission or password when using Refresh. See HP
Support Assistant for more information.
To start Refresh:
1. From the Start screen, point to the far-right upper or lower corner of the screen to display the
charms.
2. Click Settings.
3. Click Change PC settings in the bottom-right corner of the screen, and then select General
from the PC settings screen.
4. Under Refresh your PC without affecting your files, select Get started, and follow the on-
screen instructions.
Remove everything and reinstall Windows
Sometimes you want to perform detailed reformatting of your computer, or you want to remove
personal information before you give away or recycle your computer. The process described in this
section provides a speedy, simple way to return the computer to its original state. This option
removes all personal data, apps, and settings from your computer, and reinstalls Windows.
IMPORTANT: This option does not provide backups of your information. Before using this option,
back up any personal information you wish to retain.
You can initiate this option by using the f11 key.
To use the f11 key:
1. Press f11 while the computer boots.
– or –
Press and hold f11 as you press the power button.
2. Select Troubleshoot from the boot options menu.
3. Select Reset your PC, and follow the on-screen instructions.
To use the Start screen:
1. From the Start screen, point to the far-right upper or lower corner of the screen to display the
charms.
2. Click Settings.
Restore and recovery 75

HP ENVY x2 Specifications

General

Stepping	C0
Processor cache	1 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z2700 Series
Processor socket	FC-MB4760
Processor threads	4
Processor codename	Cloverview
Processor frequency	1.8 GHz
Processor cache type	L2
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor operating modes	32-bit
ECC supported by processor	No
Thermal Design Power (TDP)	- W
Motherboard chipset	-
Internal memory	2 GB
Memory clock speed	533 MHz
Memory form factor	On-board
Internal memory type	DDR2-SDRAM
Memory layout (slots x size)	1 x 2 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	64 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display surface	Matt
Display diagonal	11.6 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
Audio system	Beats Audio
Front camera resolution (numeric)	8 MP
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Operating system installed	Windows 8
Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Silver
Housing material	Metal
Country of origin	China
Processor code	SR0Z4
Processor ARK ID	70105
Processor package size	14 x 14 mm
Battery life (max)	7 h
Number of battery cells	2+2
AC adapter power	20 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	206 mm
Width	303 mm
Height	19 mm
Weight	1390 g
