Power cord set requirements10
This chapter provides power cord requirements for countries and regions.
The wide-range input feature of the computer permits it to operate from any line voltage
from 100 V ac to 120 V ac, or from 220 V ac to 240 V ac.
The three-conductor power cord set included with the computer meets the requirements
for use in the country or region where the equipment is purchased.
Power cord sets for use in other countries or regions must meet the requirements of the
country and region where the computer is used.
Requirements for all countries
These power cord requirements are applicable to all countries and regions.
The length of the power cord set must be at least 1.0 m (3.3 ft) and no more than 2.0
m (6.5 ft).
All power cord sets must be approved by an acceptable accredited agency
responsible for evaluation in the country or region where the power cord set will
be used.
The power cord sets must have a minimum current capacity of 10 A and a nominal
voltage rating of 125 V ac or 250 V ac, as required by the power system of each
country or region.
The appliance coupler must meet the mechanical conguration of an EN 60 320/IEC
320 Standard Sheet C13 connector for mating with the appliance inlet on the back of
the computer.
Requirements for
specic countries and regions
To determine power cord requirements for specic countries and regions, use this table.
Table 10-1
Power cord requirements for specic countries and regions
Country/region Accredited agency Applicable note number
Argentina IRAM 1
Australia SAA 1
Austria OVE 1
Belgium CEBEC 1
96

Table of Contents

Other manuals for HP ENVY x360

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ENVY x360 and is the answer not in the manual?

HP ENVY x360 Specifications

General IconGeneral
Form factorClamshell
Product typeHybrid (2-in-1)
Product colorSilver
Country of originChina
Bus typeDMI2
SteppingF0
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modeli5-5200U
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel® Core™ i5-5200 Mobile Series
Processor socketBGA 1168
Processor threads4
Processor codenameBroadwell
Processor frequency2.2 GHz
Processor cache typeSmart Cache
Configurable TDP-down7.5 W
Processor lithography14 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency2.7 GHz
Processor operating modes32-bit, 64-bit
ECC supported by processorNo
PCI Express configurations4x1, 2x4
Thermal Design Power (TDP)15 W
Configurable TDP-down frequency0.6 GHz
Maximum number of PCI Express lanes12
Motherboard chipset-
Memory slots1x SO-DIMM
Internal memory8 GB
Memory form factorSO-DIMM
Internal memory typeDDR3L-SDRAM
Maximum internal memory- GB
Memory layout (slots x size)1 x 8 GB
HDD speed5400 RPM
HDD interfaceSATA
Storage mediaHDD
Card reader integratedYes
Total storage capacity1000 GB
Compatible memory cardsSD, SDHC, SDXC
Number of HDDs installed1
Display diagonal15.6 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Native aspect ratio16:9
Display number of colors16.78 million colors
Intel® Virtualization Technology (Intel® VT)VT-d, VT-x
On-board graphics card ID0x1616
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 5500
On-board graphics card familyIntel® HD Graphics
On-board graphics card memory3.749 GB
Maximum on-board graphics card memory16 GB
On-board graphics card base frequency300 MHz
On-board graphics card DirectX version11.2
Number of discrete graphics cards installed0
On-board graphics card dynamic frequency (max)900 MHz
Front camera resolution1280 x 720 pixels
WWANNot installed
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version4.0
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pointing deviceTouchpad
Operating system installedWindows 8.1
Operating system architecture64-bit
Processor codeSR23Y
Processor ARK ID85212
Processor package size40 x 24 x 1.3 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version1.00
Battery capacity48 Wh
Battery life (max)- h
Number of battery cells3
AC adapter power45 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
Cable lock slot typeKensington
Operating shock40 G
Operating altitude0 - 3050 m
Non-operating shock240 G
Operating vibration1.043 G
Non-operating altitude0 - 4570 m
Non-operating vibration3.5 G
Storage temperature (T-T)-15 - 60 °C
Operating temperature (T-T)0 - 35 °C
Operating relative humidity (H-H)10 - 90 %
Sustainability certificatesRoHS, EPEAT Silver, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth250 mm
Width382 mm
Height23.9 mm
Weight2290 g
