14. If you need to remove the display panel cable:
a. Disconnect the cable from the ALS board at the top of the display back cover
(1).
b. Disconnect the cable from the two connectors on the camera module (2).
c. Disconnect the cable from the touch board at the bottom of the display back
cover (3).
d. Peel the cable o the inside of the display rear cover (4).
The display cable is available as the following spare part numbers:
N22067-001: QHD
N22068-001: FHD
N15697-001: OLED
Display assembly 75
