HP4402.book : chapter3.fm 16 Tue Apr 22 15:20:23 1997
Menu Reference
Front Panel Menu Reference "System/Inputs" Menu
3-16 HP EPM-441A User’s Guide
The softkey menu structured to this hardkey affects the system setup and
the channel setup.
Press this hardkey to access the “System/Inputs” menu. This menu allows
you to set up a variety of conditions for your power meter, for example:
HP-IB address, sensor calibration tables, averaging, duty cycle, range,
offset, service. It also allows you to review errors.
•
Press this softkey to access a menu which allows you to set the
HP-IB address and select the HP-IB command set you want to
use.
■
Press this softkey to set the HP-IB address of your power
meter between 0 and 30. The default value is 13. A pop up
window appears on the screen. Use the , , and
hardkeys to change the value. To confirm your choice
press . Refer to “HP-IB Address”, on page 2-37 for
further information.
■
Press this softkey to access a menu which allows you to select
the remote programming language you want to use. Refer to
“Programming Language Selection”, on page 2-38 for further
information.
◆
Press this softkey to select SCPI (Standard Commands for
Programmable Instruments) as the remote programming
language you want to use.
◆
Press this softkey to select the HP 437B emulation mode. In
this mode the power meter responds to the HP 437B
programming command set.
•
Press this softkey to access a menu and screen which allows you to
select and edit sensor calibration tables. Use the and
hardkeys to scroll through the displayed sensor calibration tables.
Sensor calibration tables are only required for the HP 8480 series
power sensors.
System
Inputs
HP-IB
HP-IB Addr
Enter
Command Set
SCPI
HP 437B
Sensor Cal Tables
To Next Page
