HP EPM-441A - Presetting the Power Meter; Preset Conditions Overview

HP4402.book : chapter2.fm 44 Tue Apr 22 15:20:23 1997
Power Meter Operation
Presetting the Power Meter
2-44 HP EPM-441A User’s Guide
Presetting the Power Meter
This section details the power meter’s preset conditions.
The HP-IB address and command set, the data stored in the sensor
calibration tables and the zeroing and calibration data are not affected by
a preset. The calibration table selected is not affected.
Preset Conditions
The number of windows displayed is two.
Measurement units used is set to dBm.
• is set to 50 MHz.
• is set to 100%.
• is set to digital in the upper window and
analog in the lower window.
• is set to 20.000 dBm ( ) and -70.000 dBm
().
• is set to “3”.
• is set to “Off”.
• is set to 0 dBm.
• is set to “Off”.
• is set to 0 dBm.
dBm/W
Frequency
Cal Fac
Freq
Cal Fac
Meas
Setup
Display Format
Anlg Mtr Scaling Max
Min
Resolution 1 2 3 4
Rel
Offset
Rel Off/On
Rel
Offset Off/On
Offset
