Menu Reference
Front Panel Menu Reference "System/Inputs" Menu
HP EPM-441A User’s Guide 3-17
■
Press this softkey to access a menu and screen which allows
you to modify, add and remove frequency and calibration
factors from the currently selected table and modify the table
name. Use the , , and hardkeys to move
between the name, frequency and calibration factors. Press
, or as follows:
◆
Press this softkey to modify the highlighted parameter,
which is either a frequency, calibration factor or table name.
A pop up window displays the parameter. Use the ,
, and hardkeys to change the parameter
value. To confirm your choice press .
◆
Press this softkey to insert a new sensor calibration table
entry. You are prompted to enter the frequency and
calibration factor. The entry is inserted in ascending
frequency order.
◆
Press this softkey to delete a sensor calibration table entry. If
you delete the frequency the corresponding calibration factor
is also removed and vice versa.
◆
Press this softkey to return to the measurement screen. The
softkeys from the first level of the “System/Inputs” menu are
displayed.
■
Press this softkey to enable and disable the highlighted sensor
calibration table for channel A. “ON” or “OFF” is displayed
beside each table to indicate its current state.
■
Press this softkey to return to the measurement screen. The
softkeys from the first level of the “System/Inputs” menu are
displayed.
•
Press these softkeys to access a menu which allows you to modify
the settings of the averaging, duty cycle, range and offset of
channel A.
Edit Cal Table
Change Insert Delete
Change
Enter
Insert
Delete
Done
Table Off On
Done
Input Settings
To Next Page
