HP HDX 16 User Manual

Screw listing 7–10
Phillips PM2.5×6.0 captive screw
Where used:
1 One captive screw that secures the WLAN module compartment cover to the computer (screw is secured by
a C clip)
2 Four captive screws that secure the hard drive cover to the computer (screws are secured by C clips)
Color Quantity Length Thread Head diameter
Black 5 6.0 mm 2.5 mm 5.0 mm

HP HDX 16 Specifications

General

Brand	HP
Model	HDX 16
Category	Desktop
Language	English
