Removal and replacement procedures 4–31
Display assembly
The display assembly spare part kit includes 2 WLAN antenna transceivers and cables, webcam, microphones,
and logo.
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-8).
5. Remove the following components:
a. Switch cover (see “Switch cover” on page 4-18)
b. Keyboard cover (see “Keyboard cover” on page 4-20)
c. Keyboard (see “Keyboard” on page 4-24)
d. Speaker assembly (see “Speaker assembly” on page 4-30)
Description Spare part number
16.0-inch, WXGA, AntiGlare, FHD, dual-lamp 497936-001
16.0-inch, WXGA, AntiGlare, HD, dual-lamp 496468-001
16.0-inch, WXGA, AntiGlare, HD, single-lamp 497937-001
