Removal and replacement procedures 4–61
Processor
✎
The processor spare part kit includes replacement thermal material.
Before removing the processor, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-8).
5. Remove the following components:
a. Optical drive (see “Optical drive” on page 4-9)
b. Hard drive (see “Hard drive” on page 4-11)
c. TV tuner module (see “TV tuner module” on page 4-13)
d. Memory module (see “Memory module” on page 4-15)
e. WLAN module (see “WLAN module” on page 4-16)
f. Switch cover (see “Switch cover” on page 4-18)
g. Keyboard cover (see “Keyboard cover” on page 4-20)
h. Keyboard (see “Keyboard” on page 4-24)
i. Speaker assembly (see “Speaker assembly” on page 4-30)
j. Display assembly (see “Display assembly” on page 4-31)
k. Top cover (see “Top cover” on page 4-39)
l. System board (see “System board” on page 4-45)
m. Fan/heat sink assembly (see “Fan/heat sink assembly” on page 4-58)
Description Spare part number
Intel Core2 Duo T9800 2.93-GHz processor with 6-MB L2 cache and 1066-MHz FSB 507951-001
Intel Core2 Duo T9600 2.80-GHz processor with 6-MB L2 cache and 1066-MHz FSB 500604-001
Intel Core2 Duo T9550 2.66-GHz processor with 6-MB L2 cache and 1066-MHz FSB 507953-001
Intel Core2 Duo T9500 2.53-GHz processor with 6-MB L2 cache and 1066-MHz FSB 500603-001
Intel Core2 Duo T8700 2.53-GHz processor with 3-MB L2 cache and 1066-MHz FSB 507960-001
Intel Core2 Duo T8600 2.40-GHz processor with 3-MB L2 cache and 1066-MHz FSB 500601-001
Intel Core2 Duo T8400 2.26-GHz processor with 3-MB L2 cache and 1066-MHz FSB 500600-001
Intel Core2 Duo T6600 2.20-GHz processor with 3-MB L2 cache and 1066-MHz FSB 513591-001
Intel Core2 Duo T7550 2.13-GHz processor with 3-MB L2 cache and 1066-MHz FSB 500605-001
Intel Core2 Duo T6400 2.06-GHz processor with 3-MB L2 cache and 1066-MHz FSB 513593-001
Intel Core2 Duo T7350 2.00-GHz processor with 3-MB L2 cache and 1066-MHz FSB 503392-001
