Illustrated parts catalog 3–10
Mass storage devices
Item Description Spare part number
1 Hard drives (include left and right hard drive brackets, Mylar sleeve, connector, and isolators):
500-GB, 5400-rpm 498071-001
400-GB, 5400-rpm 498072-001
320-GB, 7200-rpm 505857-001
320-GB, 5400-rpm 498069-001
250-GB, 5400-rpm 505856-001
160-GB, 7200-rpm 498068-001
160-GB, 5400-rpm 498070-001
2 Optical drives (include bezel and optical drive bracket):
Blu-ray ROM DVD±RW SuperMulti DL Drive with LightScribe 498074-001
Blu-ray ROM DVD±RW SuperMulti DL Drive 498075-001
Blu-ray ROM DVD±RW Drive 498073-001
DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe 503392-001
