Illustrated parts catalog 3–9
Item Description Spare part number
(1) Display enclosure 496462-001
Display Cable Kit, includes:
(2a) Wireless antenna transceivers and cables
(2b) Webcam/microphone module cable
(2c) Display panel cable
For use only with dual-lamp display assemblies 496465-001
For use only with single-lamp display assemblies 514289-001
(3) Display hinge cover 496464-001
Display Hinge Kit, includes: 496463-001
(4a) Display hinge bracket
(4b) Display left and right hinges
(5) Webcam/microphone module 496674-001
(6) Display inverter
For use only with dual-lamp display assemblies 496467-001
For use only with single-lamp display assemblies 488317-001
