Illustrated parts catalog 3–14
496468-001 16.0-inch, WXGA, AntiGlare, HD display assembly dual-lamp with webcam and microphone
(includes 2 WLAN antenna transceivers and cables, webcam, microphones, and logo)
496469-001 Base enclosure (includes fan, power connector cable, power connector cable bracket, subwoofer,
and 5 rubber feet)
496470-001 Top cover (includes fingerprint reader board, fingerprint reader board cable, TouchPad, and
TouchPad cables)
496471-001 Switch cover
496472-001 Keyboard cover (includes LED board and cable)
496473-001 TouchPad on/off button board (incudes cable)
496476-001 Speaker assembly
496477-001 Plastics Kit
✎
See “Plastics Kit” on page 3-7 for more Plastics Kit spare part information.
496478-001 Rubber Feet Kit (includes 5 rubber feet)
496481-001 Cable Kit
496482-001 Power button board (includes cable)
496483-001 Audio/infrared board (includes cable)
496488-001 Fan/heat sink assembly (includes replacement thermal material)
496489-001 USB board (includes cable)
496672-001 Keyboard for use in the United States (includes cable)
496672-031 Keyboard for use in the United Kingdom (includes cable)
496672-041 Keyboard for use in Germany (includes cable)
496672-051 Keyboard for use in France (includes cable)
496672-061 Keyboard for use in Italy (includes cable)
496672-071 Keyboard for use in Spain (includes cable)
496672-141 Keyboard for use in Turkey (includes cable)
496672-161 Keyboard for use in Latin America (includes cable)
496672-251 Keyboard for use in Russia (includes cable)
496672-AB1 Keyboard for use in Taiwan (includes cable)
496672-B31 Keyboard for use in the Netherlands (includes cable)
496672-BG1 Keyboard for use in Switzerland (includes cable)
496672-DJ1 Keyboard for use in Greece (includes cable)
(Continued)
Spare part number Description
To Next Page
