Illustrated parts catalog 3–16
505856-001 250-GB, 5400-rpm hard drive (includes left and right hard drive brackets, Mylar sleeve, connector,
and isolators)
505857-001 320-GB, 7200-rpm hard drive (includes left and right hard drive brackets, Mylar sleeve, connector,
and isolators)
506591-001 4096-MB memory module (667-MHz, PC2-6400, 1-DIMM)
507951-001 Intel Core2 Duo T9800 2.93-GHz processor with 6-MB L2 cache and 1066-MHz FSB (includes
replacement thermal material)
507953-001 Intel Core2 Duo T9550 2.66-GHz processor with 6-MB L2 cache and 1066-MHz FSB (includes
replacement thermal material)
507960-001 Intel Core2 Duo T8700 2.53-GHz processor with 3-MB L2 cache and 1066-MHz FSB (includes
replacement thermal material)
508199-121 Keyboard for use in French Canada (includes cable)
508199-171 Keyboard for use in Saudi Arabia (includes cable)
508199-281 Keyboard for use in Thailand (includes cable)
508199-291 Keyboard for use in Japan (includes cable)
508199-AD1 Keyboard for use in South Korea (includes cable)
508199-DH1 Keyboard for use in Denmark, Finland, and Norway (includes cable)
510485-001 90-W AC adapter for use only in Germany
513592-001 Intel Core2 Duo T6400 2.06-GHz processor with 3-MB L2 cache and 1066-MHz FSB (includes
replacement thermal material)
513593-001 Intel Core2 Duo T6600 2.20-GHz processor with 3-MB L2 cache and 1066-MHz FSB (includes
replacement thermal material)
514289-001 Display Cable Kit for use only with single-lamp display assemblies (includes wireless antenna
transceivers and cables, webcam/microphone module cable, and display panel cable)
514290-001 Fan
Spare part number Description
