Figure 5 Example P9500 disk array configurations
Electrical specifications
“System heat and power specifications” (page 22) and “System components heat and power
specifications ” (page 22) list the heat and power specifications for the P9500 disk array and
components.
Table 10 System heat and power specifications
Full Array
(DKC-0 plus
DKU RackDKC Module-1DKC Module-0
Parameter
1, 2
DKC-1 plus DKU
x4)
33.15.455.425.87Max Power
consumption
(kVA)
Heat Dissipation
and Power
Consumption
Specifications
31.45.175.155.57Max Heat
dissipation (kW)
(Maximum
configuration)
107155176431757119012Max BTUs per
hour
27002444644284791Max Kcal per hour
1
Heat (KW, BTU, Kcal) and Power (kVA) values are for determining load for site planning. Actual heat generation
and power demand may be less.
2
Calculated values with drives at a typical I/O condition. (Random Read and Write, 50 IOPSs for HDD, 2500 IOPSs
for SSD, Data Length: 8Kbytes). These values may increase for future compatible drives.
Table 11 System components heat and power specifications
Power
Consumption
(kVA)
1
Heat Output
(kW)
1
P9500 Disk Array Component
Component Product
Number
0.640
4
0.600
4
Flash Module ChassisAV375A
0.018
3
0.017
3
Flash ModuleAV392A, AV393A
1.971.88Disk Array DKC Module-0 RackAV400A
1.931.83DKC Module-1 RackAV401A, AV401B
1.541.47DKU Disk Unit RackAV402A,AV402B
see note 5see note 5Base 2.5in Drive ChassisAV411B
22 Installation requirements
