Table 1 P9500 specifications (continued)
Dual ModuleSingle ModuleSizeItem
2D+2D, 4D+4DRAID1RAID GroupConfiguration
3D+1P, 7D+1PRAID5
6D+2PRAID6
Hierarchical Star NetArchitectureInternal Path
Cache Path = 128 GB/sMaximum Bandwidth
Control Path = 64 GB/s
64 (2WL*32)32 (2WL*6)SAS 6GBack-end Path
160/16,880 /16,8FC 2/4/8GNumber of ports per
installation unit
SAS/Dual PortController chassisDevice I/F
drive chassis
Interface
Max. 6 GBpsData transfer rate
256 (2.5 inch HDD)Maximum number
of HDD per SAS I/F
8 if drives installed4 if drives installedMaximum number of CHAs
12 if diskless6 if diskless
1/2/4 GBps Fibre Channel: 16MFS/16MFLMainframeChannel I/F
2/4/8 GBps Fibre Channel: 16MUS/16MUL
2/4/8 GBps Fibre Shortwave:Open systems
8UFC/16UFC
32 cores16 coresQuantityManagement Processor
Cores
6
1
6
1
CHAsMicro Processor Blade
configuration
2 / 80 or 2 / 42DKAs
Minimum/maximum
2 / 162 / 8Cache
4 / 82 / 4Switches /CSW
Notes:
1. All CHA configuration, no DKAs (diskless system).
Table 2 Drive specifications
Speed (RPM)Drive CapacitySizeDrive Type
15,000300 GB2 1/2 inchHDD (SAS)
10,000300, 600, and 900 GB
7,200500 GB and 1 TB
n/a200, 400, and 800 GB2 1/2 inchSSD (Flash)
Dual ModuleSingle ModuleDrive ChassisDrive Type
(6 rack system)(3 rack system)
Specifications 9
