System Configuration
/RQJIRUPDW,30,FRPPDQGV¦,§XVHDQ$6&,,WUDQVFULSWLRQRIWKH,30,GDWDIRUPDW7KH
IROORZLQJH[DPSOHVLOOXVWUDWHKRZ,30,FRPPDQGVDQGUHVSRQVHVDUHVWUXFWXUHG
127($OOQRQFRPPDQGE\WHVFDQEHUHSODFHGZLWK
Long Format IPMI Command Data Structure Example
Long Format IPMI Response Data Structure Example
Bits Byte
7-2 1-0
rsSa = 0x20 0x20
NetFn = 0x07 rsLUN = 0x00 0x18
Checksum = 0xC8 0xC8
rqSWID = 0xF0 0xF0
rqSeq = 0x01 rqLUN = 0x00 0x04
Cmd = 0x04 0x04
Checksum = 0x08 0x08
Bits Byte
7-2 1-0
rqSWID = 0xF0 0xF0
NetFn = 0x07 rsLUN = 0x00 0x1C
Checksum = 0xF4 0xF4
rsSA = 0x20 0x20
rqSeq = 0x01 rsLUN = 0x00 0x04
Cmd = 0x04 0x04
Data byte 1 = 0x00 (completion code) 0x00
Data byte 2 = 0x55 (result = no error) 0x55
Data byte 3 = 0x00 (details) 0x00
Checksum = 0x83 0x83
