Follow these steps to configure the monitor port for the remote destination mirroring group in system view:
To do… Use the command… Remarks
Enter system view system-view —
Configure the monitor port
mirroring-group group-id
monitor-port monitor-port-id
Required
By default, no monitor port is
configured for a mirroring group.
• Configuring the monitor port in interface view
Follow these steps to configure the monitor port for the remote destination mirroring group in interface
view:
To do… Use the command… Remarks
Enter system view system-view —
Enter interface view
interface interface-type
interface-number
—
Configure the current port as the
monitor port
[ mirroring-group group-id ]
monitor-port
Required
By default, a port does not serve as
the monitor port for any mirroring
group.
NOTE:
• A mirroring group contains only one monitor port.
• To ensure that the port mirroring function works properly, do not enable STP, MSTP, or RSTP on the
monitor port.
• HP recommends you use a monitor port only for port mirrorin
g
. This is to ensure that the data monitorin
g
device receives and analyzes only the mirrored traffic rather than a mix of mirrored traffic and normall
y
forwarded traffic.
Configuring the remote probe VLAN for the remote destination mirroring group
Follow these steps to configure the remote probe VLAN for the remote destination mirroring group:
To do… Use the command… Remarks
Enter system view system-view —
Configure the remote probe VLAN
mirroring-group group-id
remote-probe vlan rprobe-vlan-id
Required
By default, no remote probe VLAN
is configured for a mirroring
group.
NOTE:
• HP recommends you use the remote probe VLAN for port mirroring exclusively.
• To remove the VLAN configured as a remote probe VLAN, you must first
remove the remote probe VLAN
with the undo mirroring-group remote-probe vlan command. Removing the probe VLAN can
invalidate the remote source mirroring group.
135
