To do… Use the command… Remarks
Configure the source IP address of
SNMP packets
source ip ip-address
Optional
By default, no source IP address is
specified.
The source IP address must be the
IP address of a local interface. The
local interface must be up;
otherwise, no probe packets can
be sent out.
Configure optional parameters
See “Configuring optional
parameters for an NQA test
group”
Optional
Configuring TCP tests
TCP tests of an NQA test group are used to test the TCP connection between the NQA client and a port
on the NQA server and the time for setting up a connection. The test result helps you evaluate the
availability and performance of the services provided by the port on the server.
Configuration prerequisites
TCP tests require cooperation between the NQA server and the NQA client. Before you start TCP tests,
configure a TCP listening service on the NQA server. For more information about the TCP listening
service configuration, see “Configuring the NQA server.”
Configuring TCP tests
Follow these steps to configure TCP tests:
To do… Use the command… Remarks
Enter system view system-view —
Enter NQA test group view
nqa entry admin-name
operation-tag
—
Configure the test type as TCP, and
enter test type view
type tcp Required
Configure the destination address
of TCP probe packets
destination ip ip-address
Required
By default, no destination IP
address is configured.
The destination address must be
the same as the IP address of the
listening service configured on the
NQA server.
Configure the destination port of
TCP probe packets
destination port port-number
Required
By default, no destination port
number is configured.
The destination port number must
be the same as that of the listening
service on the NQA server.
20
