12
2 System Board
Chip-Set
Chip-Set
The Intel AGPset is comprised of two chips. The 440LX PAC chip and the
PIIX4chip.
• The PAC chip is the bridge between four buses: the PL bus, the main
memory bus, the PCI bus and the AGP (graphic) bus.
• The PIIX4 chip is the bridge between three buses: the PCI bus, the SM bus
and the ISA bus. In addition, it contains the IDE controller, USB
controller and Power Management logic.
The PAC Chip (440LX)
The PAC chip, called the Intel 440LX AGPset, is contained in a Ball Grid
Array (BGA) package, giving a smaller footprint and higher reliability.
PL Bus Interface The PAC chip monitors each cycle that is initiated on the PL bus by the
processor, and forwards them to the main memory, PCI bus or AGP bus.
The chip can support one or two Pentium II processors, at up to 66 MHz PL
bus clock frequency.
PCI Bus Interface The PCI bus interface is PCI 2.1 compliant.
The PCI arbiter supports PCI bus arbitration for up to six masters using a
rotating priority mechanism. Its hidden arbitration scheme minimizes
arbitration overhead. Additional logic on the PC Workstation extends the
number of fully supported masters to seven (440LX master not counted).
AGP Bus Interface A controller for the AGP (Accelerated Graphics Port) slot is integrated in the
440LX PAC chip. Its characteristics and the AGP Bus are described in detail
in “Accelerated Graphics Port (AGP) Controller” on page 23
.
