20
2 System Board
Devices on the PCI Bus
Devices on the PCI Bus
The distribution of the interrupt lines is described more fully on page 59.
Small Computer System Interface (SCSI) Controllers
The HP Kayak XU PC Workstation has two SCSI controllers: an Ultra-wide
(16-bit) SCSI and a narrow (8-bit) SCSI.
AIC-7880 Ultra-wide
(16-bit) SCSI controller
The Adaptec AIC-7880 Ultra-wide SCSI PCI controller is integrated on the
HP Kayak XU PC Workstation system board. Data is transferred at 40 MB/s
on 16-bit wide, single-ended bus. The controller is fitted with a 16-bit SCSI
flat cable with five connectors, plus a SCSI termination device; so a maximum
PCI Device
Device
Name
PCI Bus
Number
Device
Number
Function
IDSEL
connected
to AD[xx]
Chip-set Interrupt Connection
INTA INTB INTC INTD
PL/PCI bridge
440LX PAC 0 0 0 — — — — —
Virtual PCI-to-PCI bridge (AGP)
440LX PAC 0 1 0 — — — — —
PCI/ISA bridge
PIIX4 0 7 0 AD(18) — — — —
IDE controller
1 — — — —
USB Host controller
2 — — — INT A
Power Management and SM Bus
3 — — — —
Ultra-wide (16-bit) SCSI controller
AIC-7880 0 8 0 AD(19) INT A — — —
Narrow (8-bit) SCSI controller
AIC-7860 0 9 0 AD(20) — — — INT A
PCI slot #1 (LAN)
16d 0 10h 0-7 AD(27) INT D INT A INT B INT C
PCI slot #2
17d 0 11h 0-7 AD(28) INT C INTD INT A INT B
PCI slot #3 (ARO)
18d 0 12h 0-7 AD(29) INT A INT B INT C INT D
PCI slot #4
19d 0 13h 0-7 AD(30) INT D INT A INT B INT C
AGP slot (handled through PCI-
compatible mechanisms)
— 1 0 0 — — — INT A INT B
