HP Kayak XU Technical Reference Manual

45
3 Interface Boards and Mass-Storage Drives
Connectors and Sockets
Connectors and Sockets
IDE Connector Flexible Disk Drive Data Connector
Pin Signal Pin Signal Pin Signal Pin Signal
1 Reset# 2 Ground 1 Ground 2 LDENSEL#
3 HD7 4 HD8 3 Ground 4 Microfloppy
5 HD6 6 HD9 5 Ground 6 EDENSEL
7 HD5 8 HD10 7 Ground 8 INDX#
9 HD4 10 HD11 9 Ground 10 MTEN1#
11 HD3 12 HD12 11 Ground 12 DRSEL0#
13 HD2 14 HD13 13 Ground 14 DRSEL1#
15 HD1 16 HD14 15 Ground 16 DTEN0#
17 HD0 18 HD15 17 Ground 18 DIR#
19 Ground 7 20 orientation key 19 Ground 20 STP#
21 DMARQ 22 Ground 2 21 Ground 22 WRDATA#
23 DIOW# 24 Ground 3 23 Ground 24 WREN#
25 DIOR# 26 Ground 4 25 Ground 26 TRK0#
27 IORDY 28 CSEL 27 Ground 28 WRPRDT#
29 DMACK# 30 Ground 5 29 Ground 30 RDDATA#
31 INTRQ 32 IOCS16# 31 Ground 32 HDSEL1#
33 DA1 34 PDIAG# 33 Ground 34 DSKCHG#
35 DA0 36 DA2
37 CS1FX 38 CS3FX
39 DASP# 40 Ground 6
Status Panel Connector
Battery Pack
Connector
Pin Signal Pin Signal Pin Signal
1 LCK_LED_K 2 LAN_LED_K 1 VBAT
3 Ground 4 PWR_LED_A 2
5 not connected 6 ON_OFF_C 3 NC
7 ON_OFF 8 RED_LED_A 4 Ground
9 HDD_LED_K 10 HDD_LAN_LCK
11 Reset 12 NC
13 Lock 14 Open_Detect
