3 Interface Boards and Mass-Storage Drives
Connectors and Sockets
16-Bit SCSI Connector
Pin Signal Pin Signal Pin Signal Pin Signal
1 not connected 2 not connected 35 SCD12 36 SCD13
3 not connected 4 not connected 37 SCD14 38 SCD15
5 not connected 6 not connected 39 SCDP1 40 SCD0
7 not connected 8 not connected 41 SCD1 42 SCD2
9 not connected 10 not connected 43 SCD3 44 SCD4
11 not connected 12 not connected 45 SCD5 46 SCD6
13 not connected 14 not connected 47 SCD7 48 SCDP
15 not connected 16 not connected 49 not connected 50 INT_DEV
17 TERMPWR3 18 TERMPWR4 51 not connected 52 not connected
19 RESERVED2 20 not connected 53 not connected 54 not connected
21 EXTARBACK 22 CGROUND0 55 ATN 56 not connected
23 not connected 24 not connected 57 BSY 58 ACK
25 not connected 26 not connected 59 RST 60 MSG
27 not connected 28 not connected 61 SEL 62 C_D
29 not connected 30 not connected 63 REQ 64 I_O
31 not connected 32 not connected 65 SCD8 66 SCD9
33 not connected 34 not connected 67 SCD10 68 SCD11
