3 Interface Boards and Mass-Storage Drives
Matrox Millennium II Video Controller Board
Matrox Millennium II Video Controller Board
All models are supplied with a Matrox Millennium AGP video card fitted in
the AGP accessory slot. It has the same features as the Millennium II PCI
video card supplied with the HP Vectra VL 6/xxx series PC, except that
there is no VESA connector. Its on-board MGA-2064W processor
communicates directly with the Pentium II processor along the AGP bus.
The controller can be characterized as follows:
• Support for up to 16 MB Window RAM (WRAM) at 50 ns
• External 64-bit, 220 MHz RAMDAC
• Pixel clock maximum frequency of 250 MHz
• Acceleration for 3D (texture mapping, Gouraud shading)
• Improved video scalar operations (continuous interpolation on X and Y)
• 32-bit Z buffer for CAD and OpenGL (16-bit mode is still supported)
• Bus mastering with scatter gather.
• ATX and NLX form factor compliant.
Display connector
Graphics processor chips
4 MB installed memory chips
Top and bottom halves of the
upgrade socket. (For the
installation of a video memory
upgrade module).
