Illustrations and Parts Lists 8-31
Figure 8-14 Paper Feed Guide Assembly
Table 8-17. Paper Feed Guide Assembly
Item No. Part No. Quantity Description
1 RG5-2643-000CN 1 Paper Feed Guide Assembly
2 RF5-2495-000CN 1 Shaft, Belt Idler Assembly
3 RB1-8668-000CN 1 Belt, Feed Guide
4 RB1-8674-000CN 1 Shaft, Belt Drive
2
3
4
1
For more information on the LaserJet 4000 / 4050 Visit www.PrinterSupplies.com 800-551-1943
