Illustrations and Parts Lists 8-39
Table 8-22. Paper Pickup Drive Assembly
Item No. Part No. Quantity Description
1 RG5-2672-000CN 1 Paper Pickup Drive Assembly
(500-sheet)
2 RS5-2632-000CN 1 Spring, Pickup
3 RB1-8877-000CN 1 Coupler, Pickup
4 RF5-2484-000CN 1 Pickup Roller Assembly
5 RB1-2190-000CN 1 Clip, Pickup Spring
6 RB1-8865-000CN 4 Roller, Pickup
7 RF5-2490-000CN 1 Feed, Roller
8 RB1-8879-000CN 1 Arm, Tray Sensing
