HP M34D Maintenance And Service Guide

11
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
PSU M34D
N12315-001
PLPCKL482UQB2
Capacitors and connectors are available for purchase from the following EU distributors:
 Farnell: Farnell UK - Electronic Components Distributor
 RS Component: Capacitors | RS Components (rs-online.com)
 United Chemi-Con: Digikey Electronics
Capacitors by distributor
Component
description
Location
Component
distributor
Distributor part number
EC 680uF 20% 35V
12.5*20 3000 hr 2A
ENB1
C9102
United Chemi-Con
EGPA350ELL681MK20S
C9104
C9103
C9130
Connectors by manufacturer
Component
description
Location
identifier
Component
distributor
Distributer part number
HDMI
CN501
RS
SD-47151-001(Molex)
DisplayPort
CN503
Farnell
DP1RD20JQ3(JAE)
USB Type-C
CN5101
RS
DX07S024JJ2R130(JAE）
USB B TYPE
CN1001
RS
692221030100
(Wurth Elektronik）
USB 3.0
CN1004
CN1005
Farnell
48406-0001(MOLEX）
13
KEY_FRAME
1
14
REAR COVER
1
15
STAND ASS'Y
1
16
BASE_ASS’Y
1
17
0M1G3030 4120
13
18
0M1G1030 6120
10
19
QM1G38400601200ARA
1
20
0Q1G1030 6120
8
21
0M1G2940 10 47 CR3
4

HP M34D Specifications

General

Color	black
Screen Type	led
Tiltable	yes
Wall Mount	100mm x 100mm
Touch Screen	no
Webcam	no
OS Compatibility	chrome, mac, windows
Screen Size	34 inches
Panel Type	va
Aspect Ratio	21:9
Resolution	3440 x 1440
Native Resolution	3440 x 1440
Refresh Rate	100hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	178 degrees
Response Time	5 milliseconds
Brightness	250 candela per square meter
Contrast Ratio	3500:1
Synchronization	not applicable
Horizontal Scan Rate	160 kilohertz
HDR	no
Built-In Speakers	yes
HDMI Ports	1
USB Type B Ports	0
Display Port Inputs	1
Mini Display Port	0
VGA Ports	0
DVI	0
Thunderbolt Ports	0
Headphones Output	yes
Voice Assistant	no
Depth with Stand	9.25 inches
Height with Stand	20.4 inches
Width with Stand	31.89 inches
Height without Stand	14.44 inches
Net Weight without Stand	23.17 pounds
