• The primary OS logical drive is configured as a 9 GB RAI D 1
mirror spanning drives 0 and 1.
• The secondary OS logical drive is configured as a 9 GB RAID 1
mirror spanning drives 1 and 0.
• Thedatavolumeisconfigured as a RAID 1 volume spanning the
remaining space across both drives.
Table 1 2 RAID configuration by h ard drives
Hard Drive 0
Partition C: 9GB
Primary OS
PartitionF:UserDatain
RAID-1
Hard Drive 1
Partition C: 9GB
Backup OS
PartitionF:UserDatain
RAID-1
Table 13 RAID configuration by logical drives
Logical Driv e 1
Partition C: 9GB Primary OS - RAID 1 Mirror
across physical drives 0 and 1
Logical Drive 2 Partition E: 9GB Backup OS - RAID 1 Mirror
across physical drives 1 and 0
Logical Drive 3 Partition F: Da ta volume using remaining disk
space - RAID 1 mirror spanning physical drives
0and1
The BIOS supports the following default boot seque nce:
1. CD-RW/DVD-ROM
2. HDD0,1,2
3. PXE (net work boot)
HPProLiantStorageServeruserguide
49
