Environmental requirements 71
Table 29 provides weight data for MSA 1050 controller enclosures and drive enclosures. For information about other HPE
MSA drive enclosures that may be cabled to these systems, check the QuickSpecs at:
www.hpe.com/support/MSA1050QuickSpecs
. If a website location has changed, an Internet search for
“HPE MSA 1050 quickspecs” will provide a link.
.
1
Weights shown are nominal, and subject to variances.
2
Weights may vary due to different power supplies, IOMs, and differing calibrations between scales.
3
Weights may vary due to actual number and type of disk drives (SAS or SSD) installed.
Environmental requirements
NOTE: For operating and non-operating environmental technical specifications, see the QuickSpecs at:
www.hpe.com/support/MSA1050QuickSpecs
. If a website location has changed, an Internet search for “HPE MSA 1050
quickspecs” will provide a link.
Table 28 Rackmount enclosure dimensions
Specifications Rackmount
2U Height (y-axis) 8.9 cm (3.5 inches)
Width (x-axis):
• Chassis only
• Chassis with bezel ear caps
44.7 cm (17.6 inches)
47.9 cm (18.9 inches)
Depth (z-axis):
SFF drive enclosure (2U24)
• Back of chassis ear to controller latch
• Front of chassis ear to back of cable bend
LFF drive enclosure (2U12)
• Back of chassis ear to controller latch
• Front of chassis ear to back of cable bend
50.5 cm (19.9 inches)
57.9 cm (22.8 inches)
60.2 cm (23.7 inches)
67.1 cm (26.4 inches)
Table 29 Rackmount enclosure weights
Specifications Rackmount
MSA 1050 Array SFF Enclosure
• Chassis with FRUs (no disks)
1,2
• Chassis with FRUs (including disk)
1,3
8.6 kg (19.0 lb) [chassis]
19.9 kg (44.0 lb)
25.4 kg (56.0 lb)
MSA 1050 Array LFF Enclosure
• Chassis with FRUs (no disks)
1,2
• Chassis with FRUs (including disks)
1,3
9.9 kg (22.0 lb) [chassis]
21.3 kg (47.0 lb)
30.8 kg (68.0 lb)
MSA 2050 SFF Disk Enclosure
• Chassis with FRUs (no disks)
1,2
• Chassis with FRUs (including disks)
1,3
8.6 kg (19.0 lb) [chassis]
19.9 kg (44.0 lb)
25.4 kg (56.0 lb)
MSA 2050 LFF Disk Enclosure
• Chassis with FRUs (no disks)
1,2
• Chassis with FRUs (including disks)
1,3
9.9 kg (22.0 lb) [chassis]
21.3 kg (47.0 lb)
30.8 kg (68.0 lb)
