Table 1-1 Product components and their descriptions (continued)
Category Description
RJ-45 (network) Realtek RTL8111HSH-CG (non-DASH)
S3/S5 wake on LAN with embedded NIC
The following support S3/S5 wake on LAN (via out of band): HP USB-C Universal Dock, HP USB-C Dock G4,
HP Thunderbolt Dock 120 W G2, HP USB-C Mini Dock, HP USB-C/A Universal Dock G2, and HP USB-C Dock
G5.
The following support S0/S3/S5 MAPT (via out of band): HP USB-C Universal Dock, HP USB-C Dock G4, HP
Thunderbolt Dock 120 W G2, HP USB-C Mini Dock, HP USB-C/A Universal Dock G2, and HP USB-C Dock G5.
Wireless Wireless Personal Area Network (PAN) Bluetooth
Bluetooth® 5.0 supported using combo card
Wireless Local Area Network (WLAN) (select products only)
Integrated WLAN options with dual antennas M.2 2230 socket (MIPI/BRI):
● Intel dual-band wireless-AC 9560 802.11ac 2 × 2 Wi-Fi + Bluetooth 5.0 combo adapter (non-vPro)
WLAN antennas congured at top of panel)
Supports HP LAN-Wireless Protection (WLAN/LAN switching)
Compatible with Wi-Fi CERTIFIED Miracast™ devices
Supports WoWLAN S3 AC Mode
Supports Turbo Lite Wi-Fi
Bluetooth S3 Wake-up
Ports (Input/output) Hot plug/unplug and autodetect
HDMI 1.4
One USB 2.0 + powered port (left)
Two USB 3.0 ports (right)
One USB 3.1 Gen 1 Type-C port (PD + DP) (right)
Audio-out (headphone)/Audio-in (microphone) combo jack
RJ-45 (network)
Multi-pin AC port
Sensors Accelerometer
Hall sensor
Docking HP Thunderbolt Dock 120 W G2
HP USB-C Dock G4
HP USB-C Universal Dock
HP USB-C Mini Dock
HP TB Dock G2 Audio Module
HP USB-C/A Universal Dock G2
HP USB-C Dock G5
2 Chapter 1 Product description
