HP Notebook Series

Hardware Components
Hardware Guide 1–21
Component Description
1
Power connector Connects an AC adapter.
2
Exhaust vent Allows airflow to cool internal
components. Additional vents are
on the bottom of the notebook.
Ä
To prevent overheating, do
not obstruct the vent. Do not
allow a hard surface, such as
an adjoining printer, or a soft
surface, such as bedding or
clothing, to block airflow.
3
External monitor connector Connects an optional external monitor
or overhead projector.
4
Parallel connector Connects an optional parallel device,
such as a printer.
5
RJ-11 jack (select models) Connects the modem cable.
(select models)
