Removal and Replacement Procedures
Maintenance and Service Guide 5–49
6. Disconnect the following cables from the system board:
1 RTC battery cable
2 TouchPad cable
3 Fingerprint reader board cable
7. Remove the microphone 4 from the hole in the top cover.
Disconnecting the RTC Battery, TouchPad, and Fingerprint Reader
Board Cables
