HP nx6310 - Notebook PC User Manual

A–2 Maintenance and Service Guide
Screw Listing
Phillips PM2.0×4.0 Screw Locations
Table A-1
Phillips PM2.0×4.0 Screw
Color Qty. Length Thread
Head
Width
Black 9 4.0 mm 2.0 mm 4.0 mm
Where used:
1 Two screws that secure the hard drive cover to the computer (screws are
captured on the cover by C-clips; documented in Section 5.4)
2 One screw that secures the memory/Mini Card module cover to the computer
(screw is captured on the cover by a C-clip; documented in Section 5.7)
mm

HP nx6310 - Notebook PC Specifications

General

Graphics	Intel Graphics Media Accelerator 950
Networking	10/100/1000 Gigabit Ethernet
Memory	512 MB DDR2 SDRAM
Display	15.0" XGA (1024 x 768) TFT LCD
Optical Drive	DVD-ROM
Operating System	Windows XP Professional
Battery	6-cell Lithium Ion
Chipset	Intel 945GM
Wireless	802.11a/b/g
Ports	VGA, headphone, microphone, RJ-45, RJ-11
Storage	60 GB HDD
