HP Pavilion dv1000 User Manual

Removal and Replacement Procedures
Maintenance and Service Guide 5–7
1. Loosen the two PM2.0×5.0 screws 1 that secure the hard
drive cover to the computer.
2. Lift the left side of the cover 2 and swing it to the right.
3. Remove the hard drive cover.
✎
The hard drive cover is included in the Miscellaneous
Plastics Kits, spare part numbers 367765-001 (for use on
HP Pavilion dv1000 models) and 367766-001 (for use on HP
Compaq nx4800 and Compaq Presario V2000 models).
Removing the Hard Drive Cover

HP Pavilion dv1000 Specifications

General

Processor	Intel Pentium M or Intel Celeron M
Operating System	Windows XP Home or Professional
RAM	256 MB - 2 GB DDR
Graphics	Intel GMA 900
Weight	2.4 kg
Battery Life	Up to 3.5 hours
Optical Drive	DVD-ROM
Wireless	802.11b/g
Chipset	Intel 915GM
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone
Display	14.1-inch WXGA
