HP Pavilion dv1000 User Manual

5–46 Maintenance and Service Guide
Removal and Replacement Procedures
3. Remove the tape 1 that secures the menu control button
board cable to the system board.
4. Release the ZIF connector 2 to which the menu control
button board cable is connected and disconnect the cable 3.
Disconnecting the Menu Control Button Board Cable

HP Pavilion dv1000 Specifications

General

Processor	Intel Pentium M or Intel Celeron M
Operating System	Windows XP Home or Professional
RAM	256 MB - 2 GB DDR
Graphics	Intel GMA 900
Weight	2.4 kg
Battery Life	Up to 3.5 hours
Optical Drive	DVD-ROM
Wireless	802.11b/g
Chipset	Intel 915GM
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone
Display	14.1-inch WXGA
