HP Pavilion dv1000 User Manual

5–28 Maintenance and Service Guide
Removal and Replacement Procedures
✎
Steps 12 through 15 apply only to HP Compaq nx4800 and
Compaq Presario V2000 models.
12. Remove the four PM2.0×3.0 screws 1 that secure the
keyboard to the computer.
13. Swing the rear edge of the keyboard 2 up and forward until
it rests on the palm rest.
Releasing the Keyboard, HP Compaq nx4800 and
Compaq Presario V2000 models Only

HP Pavilion dv1000 Specifications

General

Processor	Intel Pentium M or Intel Celeron M
Operating System	Windows XP Home or Professional
RAM	256 MB - 2 GB DDR
Graphics	Intel GMA 900
Weight	2.4 kg
Battery Life	Up to 3.5 hours
Optical Drive	DVD-ROM
Wireless	802.11b/g
Chipset	Intel 915GM
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone
Display	14.1-inch WXGA
