5–34 Maintenance and Service Guide
Removal and Replacement Procedures
✎
Steps 14 and 15 apply only to HP Compaq nx4800 and
Compaq Presario V2000 models.
Ä
CAUTION: Support the display assembly when removing the following
screws. Failure to support the display assembly can result in damage to
the display assembly and other computer components.
14. Remove the four PM2.0×5.0 screws 1 that secure the display
assembly to the computer.
15. Remove the display assembly 2 .
Removing the Display Assembly, HP Compaq nx4800 and
Compaq Presario V2000 models Only
Reverse the above procedure to install the display assembly
