Removal and Replacement Procedures
Maintenance and Service Guide 5–39
✎
Steps 8 and 9 apply only to HP Compaq nx4800 and Compaq
Presario V2000 models.
8. Remove the following:
1 Fifteen PM2.0×7.0 screws
2 Three PM2.0×4.0 screws
9. Lift the base enclosure 3 straight up and remove it.
Removing the Base Enclosure, HP Compaq nx4800 and
Compaq Presario V2000 models Only
Reverse the above procedure to install the base enclosure.
