HP Pavilion dv1000 User Manual

5–64 Maintenance and Service Guide
Removal and Replacement Procedures
✎
Steps 5 and 6 apply only to HP Compaq nx4800 and
Compaq Presario V2000 models.
5. Release the ZIF connector 1 to which the LED board cable is
connected and disconnect the cable 2 from the system board.
6. Remove the two PM2.0×3.0 screws 3 that secure the LED
board to the top cover.
Removing the LED Board Screws, HP Compaq nx4800 and
Compaq Presario V2000 models Only
7. Remove the LED board.
Reverse the above procedure to install the LED board.

HP Pavilion dv1000 Specifications

General

Processor	Intel Pentium M or Intel Celeron M
Operating System	Windows XP Home or Professional
RAM	256 MB - 2 GB DDR
Graphics	Intel GMA 900
Weight	2.4 kg
Battery Life	Up to 3.5 hours
Optical Drive	DVD-ROM
Wireless	802.11b/g
Chipset	Intel 915GM
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone
Display	14.1-inch WXGA
