HP Pavilion dv4000 User Manual

Removal and Replacement Procedures
Maintenance and Service Guide 5–23
3. Use a flat-blade screw driver to turn the processor locking
screw one-quarter turn counterclockwise 1 until you hear
aclick.
4. Lift the processor straight up and remove it 2.
✎
The gold triangle 3 on the processor should be aligned in the
rear right corner when you install the processor.
Removing the Processor
Reverse the above procedure to install the processor.

HP Pavilion dv4000 Specifications

General

Display	15.4-inch WXGA or WSXGA+
Operating System	Windows XP Home or Professional
Processor	Intel Pentium M or Intel Celeron M
Display Resolution	1280 x 800 or 1680 x 1050
RAM	256 MB to 2 GB
Storage	40 GB to 100 GB HDD
Graphics	Intel GMA 900 or ATI Mobility Radeon
Optical Drive	DVD±RW
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone, IEEE 1394
Wireless	802.11b/g
Battery Life	Up to 3 hours
